TPC-PCS&PRS T Series | Rich IO Touch Panel PCs with Intel 11th Gen. Core i3/i5/i7

● Modular & Fanless designed, aluminum-magnesium alloy;
● Intel 11th Gen. Tiger Lake UP3,Core i3/i5/i7 processors;
● Full dimensions, ranging from 10.1″ to 21.5″ size, quick delivery;
● Both Pcap. and Resistive touchscreen, EETI controller;
● DC 12V Power input, optional wide DC 9~36V input;
● I/O interfaces: 2 GbE, 6 USB3.0, 2 USB2.0, 6 COM, 2 HDMI;
● Intel PTT TPM2.0, Support Windows 11 OS;
● Panel mount, VESA 75/100 mount, Front IP66 rated protection;
● Optional 2 M.2 fast expansion slots.

Description

TAICENN TPC-PCS&PRT T Series is a modular all-in-one Rich IO Touch Panel PCs with Intel 11th Gen. Core i3/i5/i7 built to deliver robust computing for factory automation and industrial deployments of varying complexity. This touch panel PC leverages Intel 11th Gen Tiger Lake Core i3/i5/i7 processors to deliver responsive edge performance for real-time machine monitoring and control.

The platform supports a wide selection of industrial-grade LCD panel sizes, with both projected capacitive and resistive touch options to match your operational preferences. Built with fanless passive cooling and an IP66-rated front bezel, it maintains stable operation even in harsh workshop environments exposed to dust, splashes and frequent washdowns.

Equipped with a comprehensive I/O portfolio, the TPC-PCS & PRT T Series Rich IO Touch Panel PCs with Intel 11th Gen. Core i3/i5/i7 features dual Gigabit Ethernet ports, six USB3.0, two USB2.0, six DB9 COM interfaces, dual HDMI outputs and audio jacks for seamless connectivity with PLCs, sensors and peripheral hardware. Two M.2 expansion slots (E-key and B-key) come onboard to enable optional Wi‑Fi 6, Bluetooth, 3G/4G/5G cellular modules. This flexible expandability makes the panel PC an ideal HMI foundation for diverse industrial automation architectures.

Specification

Hardware & System	BIOS	SPI AMI EEI BIOS
	CPU	Intel 11^th Gen. Core i3-1115G4, Core i5-1155G7, Core i7-1195G7
	Graphic	Intel UHD/Iris Xe Graphic
	Memory	SO-DIMM, Support DDR4 2666/2933/3200 Mhz, Max. up to 32GB
	Storage	1* M.2 2280 M-Key slot (PCIe x4 Gen IV, NVMe) SSD, Optional support 1* 2.5” SATA III SSD
	Network	1* Intel i219V, 1* Intel i226V GbE (Optional wireless 3G/4G/LTE, Wi-Fi/BT, 5G/Wi-Fi 6)
	Audio	On-board Realtek ACL 897 Audio controller
	Expansion	1* M.2 (NGFF) B-Key 3042/3052 slot, 1* M.2 E-Key 2230 slot
	Watch dog	0 ~ 256 seconds programmable
	Operating System	Win10, Win11, Linux, Ubuntu
I/O Interface	Ethernet	2 RJ45, 10/100/1000 Mbps
	COM	COM1/2/3/4/5:RS232; COM6:RS485(Optional RS232)
	Audio	Mic-in/Line-out (2 in 1, 3.5mm Jack)
	USB	6* USB3.0, 2* USB2.0
	Display	2* HDMI (Max. support 4096 * 2160 @30Hz)
	Power	1* 2 Pins, Phenix Terminal
LCD Display & Touchsceen	Pcap. Touch	10.1" WXGA, 10.4" XGA, 12.1" XGA, 15.0" XGA, 15.6" FHD, 17.0" SXGA, 18.5" WXGA, 18.5" FHD, 19.0" SXGA, 21.5 “ FHD
LCD Display & Touchsceen	Resistive Touch	10.1" WXGA, 10.4" XGA, 12.1" XGA, 15.0" XGA, 15.6" FHD, 17.0" SXGA, 18.5" WXGA, 18.5" FHD, 19.0" SXGA, 21.5 “ FHD
Structure	Structure & Surface	Magnesium-Aluminum alloy, sand blasting, anodized treated
	Cooling System	Large area finned heatsink (Fanless designed)
	Mount Method	Panel mount, VESA 75/100 Mount
Power & Environmetal	Humidity	10 ~ 95% @ 10C (No condensation)
	Vibration	50 ~ 500 Hz, 1.5G, 0.15mm peak to peak
	Shock	10G/Peak (11 ms)
	Certificate	CE/FCC/ROHS

Ordering information

Part no.	Description
TPC-PCS101T1	10.1” LCD, WXGA 1280 * 800, Intel Core i3-1115G4, Dual-core 4.10Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS101T2	10.1” LCD, WXGA 1280 * 800, Intel Core i5-1155G7, Quad-core 4.50Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS101T3	10.1” LCD, WXGA 1280 * 800, Intel Core i7-1195G7, Quad-core 5.00Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS101T1	10.1” LCD, WXGA 1280 * 800, Intel Core i3-1115G4, Dual-core 4.10Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS101T2	10.1” LCD, WXGA 1280 * 800, Intel Core i5-1155G7, Quad-core 4.50Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS101T3	10.1” LCD, WXGA 1280 * 800, Intel Core i7-1195G7, Quad-core 5.00Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS104T1	10.4” LCD, XGA 1024 * 768, Intel Core i3-1115G4, Dual-core 4.10Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS104T2	10.4” LCD, XGA 1024 * 768, Intel Core i5-1155G7, Quad-core 4.50Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS104T3	10.4” LCD, XGA 1024 * 768, Intel Core i7-1195G7, Quad-core 5.00Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS104T1	10.4” LCD, XGA 1024 * 768, Intel Core i3-1115G4, Dual-core 4.10Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS104T2	10.4” LCD, XGA 1024 * 768, Intel Core i5-1155G7, Quad-core 4.50Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS104T3	10.4” LCD, XGA 1024 * 768, Intel Core i7-1195G7, Quad-core 5.00Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS121T1	12.1” LCD, XGA 1024 * 768, Intel Core i3-1115G4, Dual-core 4.10Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS121T2	12.1” LCD, XGA 1024 * 768, Intel Core i5-1155G7, Quad-core 4.50Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS121T3	12.1” LCD, XGA 1024 * 768, Intel Core i7-1195G7, Quad-core 5.00Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS121T1	12.1” LCD, XGA 1024 * 768, Intel Core i3-1115G4, Dual-core 4.10Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS121T2	12.1” LCD, XGA 1024 * 768, Intel Core i5-1155G7, Quad-core 4.50Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS121T3	12.1” LCD, XGA 1024 * 768, Intel Core i7-1195G7, Quad-core 5.00Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS150T1	15.0” LCD, XGA 1024 * 768, Intel Core i3-1115G4, Dual-core 4.10Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS150T2	15.0” LCD, XGA 1024 * 768, Intel Core i5-1155G7, Quad-core 4.50Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS150T3	15.0” LCD, XGA 1024 * 768, Intel Core i7-1195G7, Quad-core 5.00Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS150T1	15.0” LCD, XGA 1024 * 768, Intel Core i3-1115G4, Dual-core 4.10Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS150T2	15.0” LCD, XGA 1024 * 768, Intel Core i5-1155G7, Quad-core 4.50Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS150T3	15.0” LCD, XGA 1024 * 768, Intel Core i7-1195G7, Quad-core 5.00Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS156HT1	15.6” LCD, FHD 1920 *1080, Intel Core i3-1115G4, Dual-core 4.10Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS156HT2	15.6” LCD, FHD 1920 *1080, Intel Core i5-1155G7, Quad-core 4.50Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS156HT3	15.6” LCD, FHD 1920 *1080, Intel Core i7-1195G7, Quad-core 5.00Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS156HT1	15.6” LCD, FHD 1920 *1080, Intel Core i3-1115G4, Dual-core 4.10Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS156HT2	15.6” LCD, FHD 1920 *1080, Intel Core i5-1155G7, Quad-core 4.50Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS156HT3	15.6” LCD, FHD 1920 *1080, Intel Core i7-1195G7, Quad-core 5.00Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS170T1	17.0” LCD, SXGA 1280 * 1024, Intel Core i3-1115G4, Dual-core 4.10Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS170T2	17.0” LCD, SXGA 1280 * 1024, Intel Core i5-1155G7, Quad-core 4.50Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS170T3	17.0” LCD, SXGA 1280 * 1024, Intel Core i7-1195G7, Quad-core 5.00Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS170T1	17.0” LCD, SXGA 1280 * 1024, Intel Core i3-1115G4, Dual-core 4.10Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS170T2	17.0” LCD, SXGA 1280 * 1024, Intel Core i5-1155G7, Quad-core 4.50Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS170T3	17.0” LCD, SXGA 1280 * 1024, Intel Core i7-1195G7, Quad-core 5.00Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS185T1	18.5” LCD, WXGA 1366 * 768, Intel Core i3-1115G4, Dual-core 4.10Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS185T2	18.5” LCD, WXGA 1366 * 768, Intel Core i5-1155G7, Quad-core 4.50Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS185T3	18.5” LCD, WXGA 1366 * 768, Intel Core i7-1195G7, Quad-core 5.00Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS185T1	18.5” LCD, WXGA 1366 * 768, Intel Core i3-1115G4, Dual-core 4.10Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS185T2	18.5” LCD, WXGA 1366 * 768, Intel Core i5-1155G7, Quad-core 4.50Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS185T3	18.5” LCD, WXGA 1366 * 768, Intel Core i7-1195G7, Quad-core 5.00Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS185HT1	18.5” LCD, FHD 1920 *1080, Intel Core i3-1115G4, Dual-core 4.10Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS185HT2	18.5” LCD, FHD 1920 *1080, Intel Core i5-1155G7, Quad-core 4.50Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS185HT3	18.5” LCD, FHD 1920 *1080, Intel Core i7-1195G7, Quad-core 5.00Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS185HT1	18.5” LCD, FHD 1920 *1080, Intel Core i3-1115G4, Dual-core 4.10Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS185HT2	18.5” LCD, FHD 1920 *1080, Intel Core i5-1155G7, Quad-core 4.50Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS185HT3	18.5” LCD, FHD 1920 *1080, Intel Core i7-1195G7, Quad-core 5.00Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS190T1	19.0” LCD, SXGA 1280 * 1024, Intel Core i3-1115G4, Dual-core 4.10Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS190T2	19.0” LCD, SXGA 1280 * 1024, Intel Core i5-1155G7, Quad-core 4.50Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS190T3	19.0” LCD, SXGA 1280 * 1024, Intel Core i7-1195G7, Quad-core 5.00Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS190T1	19.0” LCD, SXGA 1280 * 1024, Intel Core i3-1115G4, Dual-core 4.10Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS190T2	19.0” LCD, SXGA 1280 * 1024, Intel Core i5-1155G7, Quad-core 4.50Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS190T3	19.0” LCD, SXGA 1280 * 1024, Intel Core i7-1195G7, Quad-core 5.00Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS215T1	21.5” LCD, FHD 1920 *1080, Intel Core i3-1115G4, Dual-core 4.10Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS215T2	21.5” LCD, FHD 1920 *1080, Intel Core i5-1155G7, Quad-core 4.50Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PCS215T3	21.5” LCD, FHD 1920 *1080, Intel Core i7-1195G7, Quad-core 5.00Ghz, Pcap. Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS215T1	21.5” LCD, FHD 1920 *1080, Intel Core i3-1115G4, Dual-core 4.10Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS215T2	21.5” LCD, FHD 1920 *1080, Intel Core i5-1155G7, Quad-core 4.50Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU
TPC-PRS215T3	21.5” LCD, FHD 1920 *1080, Intel Core i7-1195G7, Quad-core 5.00Ghz, Resistive Touch, 2 GbE, 6 USB3.0, 2 USB2.0, 2 HDMI, 6 COM, Audio, DC 12V, PSU

Optional Accessories	Description
Memory	SO-DIMM, DDR4, 4GB/8GB/16GB/32GB
Storage	M.2 SSD: 128GB/256GB/512GB
Storage	2.5” SATA SSD/HDD
Wireless	Wi-Fi Module, with Antenna
	Wi-Fi Module with BT Integrated, With Antenna
	All Network 4G module, with Antenna
	5G Network module, with Antenna
Power Supply	PSU for wide voltage DC 9 ~36V model TPC-PCS185HTxW (If needed)
SIM Card holder	SIM Card holder for 3G/4G/5G wireless function

Download

Description	Download link
TPC-PCS101T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PCS101T_EN_V32_Datasheet_260525.pdf
TPC-PCS104T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PCS104T_EN_V32_Datasheet_260525.pdf
TPC-PCS121T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PCS121T_EN_V32_Datasheet_260525.pdf
TPC-PCS150T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PCS150T_EN_V32_Datasheet_260525.pdf
TPC-PCS156HT V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PCS156HT_EN_V32_Datasheet_260525.pdf
TPC-PCS170T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PCS170T_EN_V32_Datasheet_260525.pdf
TPC-PCS185T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PCS185T_EN_V32_Datasheet_260525.pdf
TPC-PCS185HT V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PCS185HT_EN_V32_Datasheet_260525.pdf
TPC-PCS190T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PCS190T_EN_V32_Datasheet_260525.pdf
TPC-PCS215T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PCS211T_EN_V32_Datasheet_260525.pdf
TPC-PCSxxxT Series V2.0 User Manual	https://www.taicenn.com/pdf/TPC_PCSxxxT_Series_PanelPC_UserManual_EN_V20_260204.PDF

TPC-PRS101T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PRS101T_EN_V32_Datasheet_260204.PDF
TPC-PRS104T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PRS104T_EN_V32_Datasheet_260204.PDF
TPC-PRS121T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PRS121T_EN_V32_Datasheet_260204.PDF
TPC-PRS150T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PRS150T_EN_V32_Datasheet_260204.PDF
TPC-PRS156HT V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PRS156HT_EN_V32_Datasheet_260204.PDF
TPC-PRS170T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PRS170T_EN_V32_Datasheet_260204.PDF
TPC-PRS185T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PRS185T_EN_V32_Datasheet_260204.PDF
TPC-PRS185HT V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PRS185HT_EN_V32_Datasheet_260204.PDF
TPC-PRS190T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PRS190T_EN_V32_Datasheet_260204.PDF
TPC-PRS215T V3.2 Datasheet	https://www.taicenn.com/pdf/TPC_PRS211T_EN_V32_Datasheet_260204.PDF
TPC-PRSxxxT Series V1.0 User Manual	https://www.taicenn.com/pdf/TPC_PRSxxxT_Series_PanelPC_UserManual_EN_V20_260204.PDF
