Multiple platforms & Expandable Industrial Panel PC TPC-DCS&DRS Series

Multiple Intel X86 Platforms industrial Panel PC for all Industrial Application

TAICENN offers a variety of Intel X86 platforms panel PC styles in a full range of screen sizes. TPC-DCS/DRS Series is modular concept designed touch panel PC line. It can deliver basic IO ports and expansion slot to fulfill the needs of industrial computing tasks. TPC-DCS/DRS series are available with Intel® Apollo Lake J3455, Intel® 8th Gen. Whiskey Lake, Intel® Elkhart Lake J6412 and Intel® 11th Gen. Tiger Lake UP3 platforms. All our fanless panel pcs are built exclusively with Intel Embedded Roadmap components, with this, we offer up to 10 years of service and support on all of our panel pcs.

Powerful Expandable Industrial Panel PC | TPC-DCS&DRS T Series

with Intel 11th Gen. Tiger Lake UP3 Core i3/i5/i7 Platform

Basic Introduction

The TAICENN new Panel Mount Powerful Expandable Industrial Panel PC TPC-DCS&DRS T Series is a ruggedized, fan-less design with full inventory LCD display that’s crystal clear for both still imaging and streaming video. It is modular designed and manufactured by the standard Pcap. touch or resistive touch display modules and computer modules. The Powerful Expandable Industrial Panel PC TPC-DCS&DRS T series is powered by Intel’s 11th Gen. Intel Tiger Lake UP3 SoC super high computing platform (Celeron 6305E, Core i3-1115G4, Core i5-1135G7, Core i7-1165G7) processors to provide an accelerated computing performance. The integrated Intel Iris Xe Graphics built with innovative GPU architecture are able to optimize image and video handling capabilities.
The TPC-DCS&DRS T Powerful Expandable Industrial Panel PC support TPM2.0 (PTT2.0) and Windows 11 Operating systems, and 2* M.2 high speed expansional modules. The HMI touch PC system supports WiFI/BT, 3G/4G, and 5G cellular connectivity. It’s an ideal solution for various of industrial projects, including Machine-to-Machine (M2M), smart building automation, industrial automation, Industrial Internet of Things (IIoT), smart manufacturing, industry 4.0, commercial automation.

Key features

● Intel 11th Gen. Tiger Lake UP3 Celeron, Core i3/i5/i7 processors;
● 1* DDR4 memory, up to 32GB, 1* M.2 2280 (NGFF) storage;
● Projective capacitive touch or Resistive touch, EETI controller;
● Aluminum-magnesium alloy, anodized treatment, Modular designed;
● DC 12V power input, optional wide DC 9~36V input range;
● IO: 2*GLAN, 6*USB3.0, 2*COM (DB9), 2*HDMI, Audio;
● Intel PTT TPM2.0, support Windows 11;

TPC-DCS&DRS T series Image

Industrial HMI Expandable Panel PC | TPC-DCS&DRS E1 Series

with Intel Elkhart Lake J6412 Quad-core CPUs Platform

Basic Introduction

TAICENN TPC-DCS/DRS E1 series is a low power-consumption, Fan-less designed, enhanced stability and reliability Industrial HMI Expandable Panel PC product. It adapts Intel Elkhart lake J6412 high cost performance quad-core processor. TPC-DCS/DRS E1 series storage can support 1x M.2 2280 NVMe PCIe SSD. The Industrial HMI Expandable Panel PC model design with rich IO interface, includes 2 GLAN, 3 USB3.0, 3 USB2.0, 1 COM, 2 HDMI, Audio. This slim Industrial HMI Panel PC support 1 Mini-PCIe expansion slot for 3G/4G/BT/Wi-Fi wireless, also 1 M.2 key B slot support 5G wireless functions. The true flat design is available from a precision 5-wires resistive touch screen and projective capacitive touchscreen, and it can fulfill front panel NEMA/IP65 dust-proof and water-proof standards.

The Industrial HMI Expandable Panel PC TPC-DCS/DRS E1 designs with Intel PTT TPM2.0, uses full-sealed box construction, and it can prevent dust from entering the device system, is compatible with WIN10, Win11, Linux OS and Ubuntu, and it also has a good compatibility with customized applications and software programs.

Key features

● Intel Elkhart Lake Celeron J6412 processor, Quad-core 2.0Ghz;
● Pcap. touchscreen or 5-wires resistive touchscreen, EETI controller;
● DC 12V power input, optional wide voltage DC 9~36V range;
● IO: 2*GLAN, 3*USB3.0, 3*USB2.0, 1*COM (DB9), 2*HDMI, Audio;
● Fan-less & Slim design, Panel mount, VESA, Front IP65 protection.

TPC-DCS/DRS E1 Series Image

Fanless Expandable Panel PC | TPC-DCS&DRS W Series

with Intel 8th Gen. Whiskey Lake Core i3/i5/i7 CPU Platform

Basic Introduction

TAICENN TPC-DCS/DRS W series is a high performance, Fan-less designed Fanless Expandable industrial Panel PC product. It adapts Intel 8th Gen. Whiskey Lake Celeron, Core i3/i5/i7 processors. TPC-DCS/DRS W series storage can support 2.5 SATA and M.2 (PCIe) interface, HDD or SSD. The Fanless Expandable Panel PC model design with rich IO interface, includes 2 GLAN, 4 USB3.0, 3 COM, 2 HDMI. This slim Panel PC support dual M.2 expansion slots for 3G/4G/BT/Wi-Fi wireless, also support 5G/Wi-Fi6 functions. The design uses a multi-point (10- points) projective capacitive touch screen, and it can fulfill front panel NEMA/IP65 dust-proof and water-proof standards.
The TPC-DCS/DRS W Fanless Expandable Panel PC designs with Intel PTT TPM2.0, uses full-sealed box construction, and it can prevent dust from entering the device system, is compatible with WIN10, Win11, Linux OS and Ubuntu, and it also has a good compatibility with customized applications and software programs.

Key features

● Intel 8th -gen. Whiskey Lake Celeron, Core i3/i5/i7 processor;
● Pcap. or Resistive touchscreen options;
● IO: 2*GLAN, 4*USB3.0, 3*COM (DB9), 2*HDMI;
● Intel PTT TPM2.0, Support Windows 11 OS;
● Fan-less & Slim design, Panel mount, VESA, Front IP65 protection.

TPC-DCS/DRS W Series Image

Front IP65 Expandable Industrial Panel PC | TPC-DCS&DRS A1 Series

with Intel Apollo Lake J3455 Quad-core CPUs Platform

Basic Introduction

TAICENN Front IP65 Expandable Industrial Panel PC TPC-DCS/DRS A1 series is a low power-consumption Panel PC product. It adapts Intel Elkhart lake J6412 high cost performance quad-core processor. It adapts Intel Apollo lake J3455 quad-core 1.5Ghz processor. TPC-DCS/DRS A1 series storage can support 2.5 SATA and M.2 (SATA) interface, HDD or SSD. The Front IP65 Expandable Industrial Panel PC model design with rich IO interface, includes 2 GLAN, 4 USB3.0, 3 COM, 2 HDMI. This slim Panel PC support 2* M.2 expansion slots for 3G/4G/BT/Wi-Fi wireless, also support 5G/Wi-Fi6 functions. The design can fulfill front panel NEMA/IP65 dust-proof and water-proof standards.
The TPC-DCS/DRS A1 front IP65 Panel PC designs with Intel PTT TPM2.0, uses full-sealed box construction, and it can prevent dust from entering the device system, is compatible with WIN10, Win11, Linux OS and Ubuntu, and it also has a good compatibility with customized applications and software programs.

Key features

● Intel Apollo Lake J3455 processor, Quad-core 1.5Ghz;
● Aluminum-magnesium alloy, anodized treatment, Modular designed;
● IO: 2*GLAN, 4*USB3.0, 3*COM (DB9), 2*HDMI;
● Intel PTT TPM2.0, Support Windows 11 OS;
● Front IP65 water-proof and dust-proof protection.

TPC-DCS/DRS A1 Series Image

Moreover, Our panel PCs are full dimensions inventory from 10.4-inch to 21.5-inch, in 4:3 and 16:9 aspect ratios, totally 10 display selections, and with optional P-CAP or Resistive touchscreen. TAICENN Industrial Panel PC can be equipped with Intel® Apollo Lake J3455, Intel® 8th Gen. Whiskey Lake, Intel® Elkhart Lake, and Intel® 11th Gen. Tiger Lake UP3 platforms, to cover various needs for a wide range of industrial human-machine interface applications.
The TPC-DCS/DRS Series Expandable Industrial Panel PC are ideal industrial computer solutions for human-machine interface applications like machine operation monitoring, materials planning management, and plant environmental controls.
